Outdoor LED Displays
High-brightness screens built to withstand any weather
Outdoor LED Displays
Our outdoor LED displays are engineered for maximum brightness and weather resistance, perfect for billboards, sports stadiums, and city advertising.
Model Specifications
10 models from P2.0 to P16, covering all common outdoor pixel pitch requirements.
| Model | Pixel Pitch | LED Type | Pixel Density | Module Res. | Cabinet Res. | Cabinet Size |
|---|---|---|---|---|---|---|
| MX-E2 | 2.0mm | SMD1921 / 2121 | 250,000 dot/m² | 160×80 | 480×480 | 960×960mm |
| MX-E2.5 | 2.5mm | SMD1921 / 2525 | 160,000 dot/m² | 128×64 | 384×384 | 960×960mm |
| MX-E3.076 | 3.0mm | SMD2525 | 111,111 dot/m² | 104×52 | 312×12 | 960×960mm |
| MX-E4 | 4.0mm | SMD2525 / 3535 | 62,500 dot/m² | 80×40 | 240×240 | 960×960mm |
| MX-E5 | 5.0mm | SMD3535 | 40,000 dot/m² | 64×32 | 192×192 | 960×960mm |
| MX-E6 | 6.0mm | SMD3535 | 27,777 dot/m² | 32×32 | 160×160 | 960×960mm |
| MX-E6.67 | 6.67mm | SMD3535 | 22,500 dot/m² | 48×24 | 144×144 | 960×960mm |
| MX-E8 | 8.0mm | SMD3535 | 15,625 dot/m² | 40×20 | 120×120 | 960×960mm |
| MX-E10 | 10.0mm | SMD3535 / DIP346 | 10,000 dot/m² | 32×16 | 96×96 | 960×960mm |
| MX-E16 | 16.0mm | DIP346 / SMD3535 | 3,906 dot/m² | 20×10 | 60×60 | 960×960mm |
Outdoor LED Display Applications
MAXV outdoor LED displays are engineered for permanent outdoor installations in demanding environments. From sun-exposed billboards to coastal installations, our IP65-rated cabinets handle it all.
Billboards & Digital Billboards
High-brightness 5,000-10,000 nit displays visible in direct sunlight. Built for 24/7 operation in all weather conditions.
Sports Stadiums & Arenas
Large-format perimeter LED boards and scoreboard displays with wide viewing angles for audiences at any seat position.
Transit & DOOH Advertising
Advertising screens in airports, train stations, bus terminals, and metro systems. Remote monitoring for maintenance-free operation.
Building Facade Installations
Large-scale LED walls that transform building exteriors into dynamic digital canvases for advertising and artistic displays.
Rental & Event Productions
Temporary outdoor event setups for concerts, festivals, and sports broadcasts with quick-install cabinet systems.
Why MAXV Outdoor LED Displays Stand Apart
IP65 Weather Resistance
Full IP65-rated protection on the front panel and IP54 on the rear. Operates reliably in rain, dust, humidity, and extreme temperatures from -20C to 60C.
5,000-10,000 Nits Brightness
Ultra-high brightness ensures perfect visibility in direct sunlight. Automatic brightness adjustment based on ambient light conditions.
Anti-Corrosion Cabinet Treatment
Electrophoretic coating and sealedcabinet design prevent corrosion from salt air, pollution, and coastal environments.
Energy Efficient Design
Advanced driver ICs and PWM technology reduce power consumption by up to 30% compared to standard outdoor LED displays.
Frequently Asked Questions
Quick answers to common questions about our outdoor LED displays.
What brightness do outdoor LED displays need?
Outdoor LED displays typically require 5,000-8,000 nits brightness to remain visible under direct sunlight. Our outdoor series delivers up to 7,000 nits with automatic brightness adjustment that adapts to ambient light conditions, saving power at night.
Are outdoor LED displays waterproof?
Yes. MAXV outdoor LED displays feature IP65 front protection and IP54 rear protection, ensuring reliable operation in rain, dust, and extreme weather. All cabinets undergo 48-hour waterproof testing before shipment.
What is the typical viewing distance for outdoor displays?
For outdoor displays, viewing distance correlates with pixel pitch. P4-P6 is ideal for distances of 5-20m (billboards, building wraps). P8-P10 works well for 15-40m (highway billboards, stadium screens). We recommend P6 as the most versatile outdoor pitch.
How are outdoor LED displays cooled?
Our outdoor cabinets use natural convection cooling with aluminum heat sinks and intelligent fan systems. The temperature-controlled fans activate only when needed, reducing power consumption and extending component life.
Can outdoor LED displays operate in extreme temperatures?
Yes. Our outdoor LED displays are designed to operate in temperatures ranging from -20C to +60C. The combination of intelligent fans, high-quality ICs, and thermal management ensures stable performance even in desert heat or freezing winter conditions.
What is the lifespan of outdoor LED displays?
MAXV outdoor LED displays have a lifespan of 100,000+ hours. The outdoor models use industrial-grade components with enhanced protection against UV radiation, moisture, and temperature fluctuations to ensure longevity in harsh environments.
Do outdoor displays support automatic brightness adjustment?
Yes. All our outdoor displays include built-in ambient light sensors that automatically adjust brightness from 200 to 7,000 nits. This saves up to 40% power consumption at night while maintaining optimal visibility during the day.
What maintenance is required for outdoor LED displays?
Routine maintenance includes periodic visual inspection, cleaning of air intake vents, and checking seals. Our displays support front and rear service. Recommended inspection schedule: monthly for high-dust areas, quarterly for normal environments.
